12
5) After cleaning the dust cup assembly, please install the filter into the filter
cover firstly and then put them into the dust cup, after it, install the dust
cup into the handheld unit.(see Fig 6-5)
7) Scratch along the locating slot of roll brush with blade to cut and clean the
hair. After that, re
install the floor brush and close the roll brush cover.
(Notes: Do not use the blade on the floor rolling brush itself to cut wound
materials)(Fig. 6-6c)
Fig. 6-5
6) If there is hair in the floor brush, push the release button (8) in the side of
floor brush, and then press the roll brush release tab (7) as shown below to
open the roll brush cover, and then remove the roll brush (9). (see Fig 6-6a /
see Fig 6-6b )
Fig. 6-6a Fig. 6-6b
(9)
(8)
