14
INSTALLATION
Turntable Installation
Remove all packing material and accessories.
Examine the microwave oven for any damage such as dents or a broken door. Do not install if
the microwave oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the microwave oven cavity to
protect the magnetron.
Select a level surface that provides enough open space for the intake and / or outlet vents.
1.
20cm
30cm
20cm
min85cm
0cm
The minimum installation height is 85cm.
The rear surface of the microwave oven shuld be placed against a wall.
Leave a minimum clearance of 30cm above the microwave oven, and a minimum
clearance of 20cm between the microwave oven and any adjacent walls.
Do not remove the legs from the bottom of the microwave oven.
Blocking the intake and/ or outlet openings can damage the microwave oven.
Place the microwave oven as far away from radios and TVs as possible. Operation of a
microwave oven may cause interference to your radio or TV reception.
(1)
(2)
(3)
(4)
(5)
Plug your microwave oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage and the frequency on the rating label.
2.
WARNING: Do not install the microwave oven over a cooktop or other heat- producing
microwave oven. If installed near or over a heat source, the microwave oven could be damaged
and the warranty will be void.
The accessible surface may be hot during
operation.
Installation
