INSTALLATION
Prepare for installation:
If you have an outlet that leads outside, it is possible to connect your cooker hood to an
extraction duct using materials such as enamel, aluminum, flexible pipe, or inflammable
material with an interior diameter of 150mm, as shown in the picture below.
A.
Before installation, turn the unit o and unplug it from the outlet.
B.
The cooker hood should be placed at a distance of 65~75cm above
the cooking plane for the best eect.
C.
Installation (Vent outside):
Attention! Observe the warning in the instruction sheet concerning the operation of the
appliance when air is discharged from the room.
7
GB
Drill 3 holes to accommodate the bracket. Screw and tighten the bracket onto the wall with
the screws & screw plugs provided.
1.
Holes on wall
Screw plug
Wall bracket
Screw
(4mm x 30mm)
