INSTALLATION
Prepare for installation:
If you have an outlet that leads outside, it is possible to connect your cooker hood to an
extraction duct using materials such as enamel, aluminum, flexible pipe, or inflammable
material with an interior diameter of 120mm, as shown in the picture below.
A.
Before installation, turn the unit o and unplug it from the outlet.
B.
The cooker hood should be placed at a distance of 65~75cm above
the cooking plane for the best eect.
C.
Method One:
To install onto the wall, drill 2 holes of Ø8mm in a suitable place
according to the center distance of the hole in the back of the
cooker hood.
Insert the nut into the holes.
Insert the screws into the nuts and tighten them.
Put the cooker hood onto the tightened screws.
Fix the cooker hood with a safety screw. The two safety vents
are positioned on the back casing, with a diameter of 6mm.
Put the one-way valve onto the cooker hood.
Method Two:
Drill 4 holes of 6mm diameter at the bottom of the hanging
cupboard.
Put the one-way valve on the cooker hood, then install the
cooker hood on the bottom of the hanging cupboard, and
tighten the hood with enclosed 4 screws.
7
