8
refrigerator is scrapped, it shall be kept away from any fire source and be recovered by a special recovering
company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the
environment or any other harm.
Ø When the refrigerator is scrapped, disassemble the doors, and remove gasket of door and shelves; put the doors
and shelves in a proper place, so as to prevent trapping of any child.
Reversing the Door Swing
1. Make sure that your refrigerator is unplugged.
2. Pry hole covers and screws，then pry the top cover up
and remove the three screws that secure the upper hinge
to the door, then remove the hinge.
3. Remove the refrigerator compartment door from the
cabinet.
4. Remove the screws that secure the lower hinge to the
right side of the cabinet, then remove the hinge.
5. Remove the washer and nut that secure the pin shaft to
the right hole on the lower hinge, then remove the shaft
6. Insert the pin shaft into the left hole on the lower hinge,
then secure the shaft with the washer and nut.
7. Install the lower hinge on the left side of the cabinet.
10. Remove the screw that secures the door stop from the
bottom right of the refrigerator compartment door, then
remove the door stop and install to the bottom left side.
8. Install the refrigerator compartment door.
9. Move the door bushing from the top right side of the
refrigerator door to the top left side of the door. And move
the left hole cover to the right side.
10. Secure the upper hinge to the top left side of the
cabinet with the three screws you removed previously.
Before you tighten the upper hinge screws, make sure
that the top of the door is level with the cabinet and that
the rubber gasket makes a good seal.
11. Install the top cover over the cabinet.
Refrigerator
door
