INDICATOR LIGHT FUNCTION
RED BLUE
Indicator Light (Scene Red/Blue)
Main motor overcurrent/short
circuit
Brush current/short circuit
No-load protection (main motor)
Overvoltage /overcurrent of
the adaptor
Battery pack undervoltage
shutdown 2.75V
Battery low voltage protection
NTC Short circuit or open circuit
The red light is on for 10 seconds, meanwhile the
machine stop working (If you press switch when
device is on and it does not turn on)
The red and blue lights flash alternately
(The main motor works normally)
After the blue indicator is on for 2 seconds,
the red indicator blinks at 2 Hz for
3 seconds (6 times), and the system shuts down
The red light blinks 10 times at 1hz
The red light blinks for 10 seconds(2hz) (20times)
(Every time the blue light flashes after switching
o)
When the battery pack voltage is less than or
equal to 14v, the battery pack cannot be charged
and blinks red at 2hz for 10 times
If the battery pack is not charged or discharged,
the red light blinks at 2hz for 14 times
12
