PAUSE and RESTART function.
When used in combination with other buttons this accesses the user menu.
The Defrost function is used to defrost foodstuffs or gently melt butter, chocolate or
honey ...etc.
When used in combination with other buttons this accesses the installer menu.
When a pan is placed on one of the 4
cooking areas, the hob automatically
detects its presence and lights up the
corresponding digit to activate it.
If there are no pans or other objects on
the hob, the digits are not visible.
The functions which can be selected are
always visible on the control panel, but
with a dimmed light. Select the functions
by touching the corresponding symbol.
9. POWER LIMITATION
When connecting to the domestic power
supply for the first time, the installer
must set the power of the cooking areas
based on the actual capacity of the do-
mestic power supply.
If this is not necessary, the hob can be
turned on directly using
, otherwise,
follow the operations below to access
the menu.
Before carrying out the procedure it is
advisable to read the entire paragraph.
Connect the hob to the domestic mains
power.
When the power is first turned on, the
symbol
flashes.
Continuing to hold , press the 4 Digits
for the cooking areas (
) one at a time
in an anticlockwise direction, starting
from the one on the right.
A beep sounds each time you press,
and when button
is released it
shows:
and will appear alternately on the
rear left Digit.
will appear on the front left Digit.
Press the rear left Digit and number 8 on
the power bar to enter the settings
menu. This operation is confirmed by
the display (
and ) switching to (
and . ).
We are now in the hob power settings
menu.
Press the front left Digit and select one
of the values displayed on the power bar
(0-1-2-3-) following the table below.
Value on the
power bar
KW Notes
0 7.4
Standard initial setting
1 4.5
2 3.5
3 2.8
Once the correct value has been
entered, confirm by touching and hold-
ing
.
12
