16 17
5) Remove the door end cover, install the upper hinge sleeve and door
signal line to the other side and install the door end cover.
Dismantle the door stopper,sleeve pipe from the right bottom of door,
insert the sleeve pipe into hinge hole of left bottom of door, assemble
door stopper on left bottom of door.
6) Take out the left top hinge , left top hinge cover from accessories
package ,place the door on bottom hinge ,and mount left top hinge.
Connect signal line terminal with signal line terminal , connect
signal line terminal with signal line terminal ,mount top hinge
cover and hole cover.
door signal line
sleeve pipe
sleeve pipe
stopper
stopper screw
door end cover
7) For the assembly of the handle, please refer to chapter 2.2.
(Above is only for reference. The actual configuration will depend on the
After transportation, please let the refrigerator
stay for more than 2 hours before turning on the
power, otherwise it will lead to a decrease in
cooling capacity or a damage to the refrigerator.
(Above is only for reference. The actual configuration will depend on the
physical product or statement by the distributor)
2.5 Changing the Light (optional)
2.6 Starting
Before putting any fresh or frozen foods, the
refrigerator must run for 2-3 hours, or for above
4 hours in summer when the ambient
temperature is high. Please pull out plug in case of power failure or
cleaning. Do not connect the freezer to power supply within five minutes
to prevent damages to the compressor due to successive starts.
hinge cover
hole cover
Any replacement or maintenance of the LED lamps is intended to be
made by the manufacturer, its service agent or similar qualified person.
physical product or statement by the distributor).
