User’s Manual of WGS-4215 Series
22
1.5 Product Specifications
Product
WGS-4215-8P2X
WGS-4215-8P2XV
Hardware Specifications
Copper Ports
8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP+ Slots
2 100/1G/2.5G/10GBASE-X SFP+ interfaces
PoE Injector Port
8 ports with 802.3at PoE+ injector function (Ports1 to 8)
LCD Monitor
-
2.4-inch TFT color touchscreen
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
Connector
4-pin terminal block for power input
- Pin 1/2 for Power 1 (Pin 1: V+ / Pin 2: V-)
- Pin 3/4 for Power 2 (Pin 3: V+ / Pin 4: V-)
2-pin terminal block for event alarm
Alarm
One relay output for power failure. Alarm Relay current carry ability: 1A @ 24V
DC
Enclosure
IP30 metal case
Installation
Wall-mount
Dimensions (W x D x H)
245 x 36 x 140 mm
Weight
914g
930g
Power Requirements
48~54V DC
(>52V DC for PoE and PoE+ output recommended)
Dual power input is required for maximum power loading
Maximum current 7.5A
Power
Consumption
System on
Max. 15.7 watts/53.57 BTU @54V DC
input (288-watt PoE Budget)
Max. 15.8 watts/53.91 BTU @54V DC
input (288-watt PoE Budget)
Full loading
with PoE
function
Max. 344.3 watts/1174.80 BTU @Dual
54V DC input (288-watt PoE Budget)
Max. 337.3 watts/1150.92 BTU @Dual
54V DC input (288-watt PoE Budget)
ESD Protection
6KV DC
LED Indicator
System:
PWR 1(Green)
PWR 2 (Green)
Ring (Green)
Ring Owner (Green)
Per 10/100/1000T RJ45 PoE Ports:
100/1000 LNK/ACT (Green)
10/100 LNK/ACT (Amber)
802.3af/at PoE-in-Use (Amber)
Per SFP+ Interface:
1G/2.5G LNK/ACT (Green)
10G LNK/ACT (Amber)
