13
LS200-MF8
z Indoor Temperature and Humidity Sensor (-20 °C to 55 °C)
z PIR Sensor (3 m to 5 m)
z Light Sensor (1 Lux to 3000 Lux)
z Tilt Sensor (Conversion Angle: 45° ±5° degrees)
z Vibration Sensor
z Reed Switch Sensor
z Glass Break Sensor (Detection Mode: Piezoelectric buzzer)
z LoRaWAN™ Class A compatible
LS250-PLUG
z Power Plug with Power Meter
z Maximum 16 A current measurement
z IP20 rating
z LoRaWAN™ Class C compatible
1.4ProductSpecications
LS100 series (WL/PIR/DW)
Product LS100-WL LS100-PIR LS100-DW
Wireless Transmission
Technology LoRaWAN
Frequency
EU868: 863 to 870 MHz
US915: 902 to 928 MHz
TX Power
US915: 20 dBm EU868: 16 dBm
AS923: 16 dBm (optional) KR920: 14 dBm (optional)
AU915: 20 dBm (optional) IN865: 20 dBm (optional)
Rx Sensitivity
-136 dBm (LoRa, Spreading Factor = 12, Bitrate = 293 bps)
-121 dBm (FSK, Frequency Deviation = 5 kHz, Bitrate = 1.2 kbps)
Work Mode OTAA/ABP Class A
Data Interfaces
Power Supply
2 x 3.6 V ER14505 AA battery in parallel
(Battery not included)
2 x 3.0 V CR2450
button battery
(Battery not included)
Operating Voltage DC 3.1 V to 3.65 V DC 3.1 V to 3.65 V DC 2.4 V to 3 V
