21
LS200-MF8
Product LS200-MF8
Wireless Transmission
Technology LoRaWAN
Frequency
EU868: 863 to 870 MHz
US915: 902 to 928 MHz
TX Power
US915: 20 dBm EU868: 16 dBm
AS923: 16 dBm (optional) KR920: 14 dBm (optional)
AU915: 20 dBm (optional) IN865: 20 dBm (optional)
Rx Sensitivity
-136 dBm (LoRa, Spreading Factor = 12, Bitrate = 293 bps)
-121 dBm (FSK, Frequency Deviation = 5 kHz, Bitrate = 1.2 kbps)
Work Mode OTAA/ABP Class A
Data Interfaces
Power Supply 2 x 3.0 V CR2450 button battery (Battery not included)
Operating Voltage DC 2.3 to 3V
Battery Life Time
2.26 years
(25 °C, 60-minute reports, TX power = 20 dBm, SF10)
Low Battery Threshold 2.4 V
Physical Characteristics
Dimensions (L x W x H) 75.5 mm x 19.4 mm x 44 mm
Weight 120 g
Sensor Dimensions
(L x W x H)
Reed Switch: 46 mm x 16 mm x 12.9 mm
Glass Break Sensor: 36 mm x 36 mm x 7.9 mm
Sensor Weight -
Sensor Measurement
Info
Temperature Sensor
- Measurement Range: -20 °C to 55 °C
- Measurement Accuracy: ±1 °C
Humidity Sensor
- Measurement Range: 0 % RH to 100 % RH
- Measurement Accuracy: ±7 % RH
Passive Infrared Sensor
- Detectable Angle: 80° horizontally/55° vertically
- Detectable Range: 3 m to 5 m
Light Sensor
- Illumination Measurement Range: 1 lux to 3000 lux
- Illumination Measurement Accuracy: < 15 %
