17
Sensor
Measurement Info
Temperature Sensor
- Measurement Range:
-20 °C to 55 °C
- Measurement
Accuracy: ±1 °C
Humidity Sensor
- Measurement Range:
0 % to 100 % RH
- Measurement
Accuracy: ±4 % RH
Temperature Sensor
- Measurement Range:
-40° to 125 °C
Temperature Sensor
- Measurement Range:
-40° to 125 °C
Ingress Protection IP65 IP65 IP65
Operating
Temperature
-20 °C to 55 °C
Relative Humidity < 90 % RH (non condensing)
Storage
Temperature
-40 °C to 85 °C
Standards Conformance
Regulatory
Compliance
CE RED, FCC PART 15B
LS200 series (RF/LG/CM3)
Product LS200-RF LS200-LG LS200-CM3
Wireless Transmission
Technology LoRaWAN
Frequency
EU868: 863 to 870 MHz
US915: 902 to 928 MHz
TX Power
US915: 20 dbm EU868: 16 dbm
AS923: 16 dbm (optional) KR920: 14 dbm (optional)
AU915: 20 dbm (optional) IN865: 20 dbm (optional)
Rx Sensitivity
-136 dBm (LoRa, Spreading Factor = 12, Bitrate = 293 bps)
-121 dBm (FSK, Frequency Deviation = 5 kHz, Bitrate = 1.2 kbps)
Work Mode OTAA/ABP Class A
Data Interfaces
Power Supply
2 x 3.6 V ER14505 AA battery in parallel (Battery not included)
Operating Voltage
DC 3.1 V to 3.65 V DC 3.1 V to 3.65 V DC 3.1 V to 3.65 V
Battery Life Time
5 years (25 °C, 15-minute reports, TxPower=20 dBm, SF10)
Standby Current
20 μA 17 μA 25 μA
