IGT-2205AT-E
1
Flexible, Reliable and Industrial-grade Network Distance Extension Solution
PLANET IGT-2205AT-E is an industrial-grade Gigabit media converter that
provides non-blocking wire-speed performance and high flexibility for extending
Gigabit Ethernet in harsh industrial environments. It is equipped with two
10/100/1000BASE-T RJ45 copper ports and two 100/1000BASE-X SFP ber optic
interfaces, enclosed in a rugged IP40-rated case with a redundant power system.
The IGT-2205AT-E is ideal for applications such as surveillance deployment,
industrial control, and wireless service in environments with extreme temperatures
ranging from -40 to 75 degrees C.
Fiber-Optic Link Capability Enables Extension of Network Deployment
The two SFP slots are compatible with 100BASE-FX and 1000BASE-X ber-optic
transceivers. The robust fiber uplink capability ensures stable throughput for all
connected network nodes. Gigabit Ethernet transmission can be extended up to
300 meters over multi-mode fiber and up to 10/20/30/40/50/70 kilometers over
single-mode fiber. Fast Ethernet can be extended up to 2 kilometers with multi-
mode ber or up to 20/40/60 kilometers with single-mode ber. This makes it well-
suited for use in factory data centers and distribution networks.
Physical Port
• 2-port 10/100/1000BASE-T RJ45 with auto MDI / MDI-X
function
• 2-port SFP, supporting 100/1000BASE-X transceiver type auto
detection
Fiber Port Redundancy (This function is only
enabled when DIP Switch 1 is set to ON)
• Only primary port is active at a time, while the backup port is
blocked.
• When primary port link failure occurs, the trafc will swap to
back up port automatically.
• Once the primary port status is back to link up, the trafc will
swap from backup port to primary port.
Layer 2 Features
• Supports auto-negotiation and 10/100Mbps half / full duplex
and 1000Mbps full duplex mode
• High-performance Store and Forward architecture, runt/CRC
ltering eliminates erroneous packets to optimize the network
bandwidth
• IEEE 802.3x ow control for full duplex operation and back
pressure for half duplex operation
• 10K jumbo frame size support
• Integrated address look-up engine, supporting 8K absolute
MAC addresses
• Automatic address learning and address aging
Industrial Case and Installation
• Slim IP40 metal case protection
• DIN-rail, side wall-mount design for redundant power design
• Redundant Power Design
– 12 to 58V DC, redundant power with reverse polarity
protection function
• Supports 4000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
Industrial Compact 2-Port 10/100/1000BASE-T to 2-Port
100/1000BASE-X SFP Media Converter
Outdoor
IP Camera
IGT-2205AT-E IGT-2205AT-E
240km
Fiber Optic Cable
up to
120km
Fiber Optic Cable
up to
120km
Extending Ethernet Distance
Ethernet up to
100 meters
Outdoor
IP Camera
Ethernet up to
100 meters
Network Video
Recorder
Gigabit Fiber Switch
