IGS-800T-PN/IGS-820TF-PN
5
Specications
Model
IGS-800T-PN IGS-820TF-PN
HardwareSpecications
Copper Ports
8 x 10/100/1000BASET RJ45 TP auto-MDI/MDI-X,
auto negotiation
6
x 10/100/1000BASE-T RJ45 TP auto-MDI/MDI-X,
autonegotiationports(Ports1to6)
Connector
Removable4-pinterminalblock
Pin 1/2 for Power 1; Pin 3/4 for Power 2
SFP Slots -
2x1000BASE-XSFPinterfaces(Ports7to8)
Backwardcompatiblewith100BASE-FXtransceiver
ESD Protection 6KV
EFT Protection 6KV
Power Requirements
9~48V DC redundant power with polarity reverse protection function,
24V AC power support
Power Consumption / Dissipation
System on: Max. 0.48 watts/1.6BTU
Ethernet Full Loading: Max. 2.88 watts/9.8BTU
System on: Max. 1.44 watts/4.9BTU
Ethernet Full Loading: Max. 4.8 watts/16.4BTU
Installation DIN-railkitandwall-mountear
Enclosure IP30 metal case
Dimensions(WxDxH) 41 x 70 x 115 mm
Weight 305g 345g
LED
2 x LED for system and power:
■Green: DC Power 1
■Green: DC Power 2
2 x LED for each copper port:
■Green:1000MbpsLNK/ACT
■Amber:10/100MbpsLNK/ACT
2 x LED for system and power:
■Green: Power 1
■Green: Power 2
2 x LED for each port:
■10/100/1000TRJ45Ports:
Green:1000MbpsLNK/ACT
Amber:10/100MbpsLNK/ACT
■100/1000BASE-XSFPInterfaces:
Green:1000MbpsLNK/ACT
Amber:100MbpsLNK/ACT
SwitchSpecications
Switch Processing Scheme Store-and-Forward
Address Table 4Kentries
Buffer Memory 4M bits on-chip buffer memory
Flow Control
Backpressureforhalfduplex
IEEE 802.3x pause frame for full duplex
Switch Fabric 16Gbps
Throughput(packetpersecond) 11.9Mpps@64bytes
Jumbo Frame 9Kbytes
NetworkCables
10/100/1000BASE-T
Cat.3,4,5,5e,6UTPcable(max.100meters)
EIA/TIA-568100-ohmSTP(max.100meters)
PROFINET Support ConformanceClassA(CC-A),PTCPlter,QoSprioritization
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE802.3azEnergyEfcientEthernet
IEEE 802.1p Class of Service
PROFINET protocol
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32(freefall)
IEC60068-2-27(shock)
IEC60068-2-6(vibration)
PROFINET Conformance Class Conformance-Class A
Environment
Temperature
Operating: -40~75 degrees C
Storage: -40~75 degrees C
Humidity Operating:5~90%,Storage:5~90%(non-condensing)
Humidity
Operating:5~95%(non-condensing)
Storage:5~95%(non-condensing)
