13
5. Three-View Diagram
The three-view diagram of the Industrial PROFINET Switch consists of multiple
auto-sensing 10/100/1000BASE-T RJ45 ports, 100/1000X SFP (Fiber ports available
on IGS-820TF-PN only) and one removable terminal block. The LED indicators are
also located on the front panel.
IGS-800T-PN
115.00
41.00
70.00
18.00
3.50
103.00
5.50
DC Input: 9-48V
, 1A max.
AC Input: 24V
, 0.5A max.
V1+ V2+
PWR2PWR1
1 2 3 4
Side View Front View
Mounting Kit
Mounting Kit
DIN-Rail Kit
Side View
Rear View
Top View
Bottom View
Dimensions (W x D x H): 41 x 70 x115 mm
P1 P2
12
34
56
78
IGS-800T-PN
1000 LNK/ACT
10/100 LNK/ACT
PROFINET
Figure 8: IGS-800T-PN_three-view drawing
