User’s Manual of IGS-5225 series
99
IP Interface
Delete
Select this option to delete an existing IP interface.
VLAN
The VLAN associated with the IP interface. Only ports in this VLAN will be
able to access the IP interface. This field is only available for input when
creating a new interface.
IPv4
DHCP
Enabled
Enable the DHCP client by checking this box.
Fallback
The number of seconds for trying to obtain a DHCP lease.
Current
Lease
For DHCP interfaces with an active lease, this column shows the current
interface address, as provided by the DHCP server.
IPv4
Address
Provide the IP address of this Managed Switch in dotted decimal notation.
Mask
Length
The IPv4 network mask, in number of bits (prefix length). Valid values are
between 0 and 30 bits for an IPv4 address.
DHCPv6
Enable
Enable the DHCPv6 client by checking this box. If this option is enabled,
the system will configure the IPv6 address of the interface using the
DHCPv6 protocol
Rapid
Commit
Enable the DHCPv6 Rapid-Commit option by checking this box. If this
option is enabled, the DHCPv6 client terminates the waiting process as
soon as a Reply message with a Rapid Commit option is received.
This option is only manageable when DHCPv6 client is enabled.
Current
Lease
For DHCPv6 interface with an active lease, this column shows the
interface address provided by the DHCPv6 server
IPv6
Address
Provide the IP address of this Managed Switch. An IPv6 address is in 128-
bit records represented as eight fields of up to four hexadecimal digits with
a colon separating each field (:).
Mask
Length
The IPv6 network mask, in number of bits (prefix length). Valid values are
between 1 and 128 bits for an IPv6 address.
IP Routes
Delete
Select this option to delete an existing IP route.
Network
The destination IP network or host address of this route. Valid format is
dotted decimal notation or a valid IPv6 notation. A default route can use the
value 0.0.0.0 or IPv6 :: notation.
Mask Length
The destination IP network or host mask, in number of bits (prefix length).
Gateway
The IP address of the IP gateway. Valid format is dotted decimal notation or
a valid IPv6 notation. Gateway and Network must be of the same type.
Next Hop VLAN
The VLAN ID (VID) of the specific IPv6 interface associated with the
gateway.
Buttons
: Click to add a new IP interface. A maximum of 128 interfaces are supported.
: Click to add a new IP route. A maximum of 32 routes are supported.
: Click to apply changes.
: Click to undo any changes made locally and revert to previously saved values.
