User’s Manual of IGS-5225 series
94
4.1.1 Main Web page
The Industrial Managed Switch provides a Web-based browser interface for configuring and managing it. This interface
allows you to access the Industrial Managed Switch using the Web browser of your choice. This chapter describes how to
use the Industrial Managed Switch’s Web browser interface to configure and manage it.
Figure 4-1-4: Main page
Panel Display
The web agent displays an image of the Industrial Managed Switch’s ports. The Mode can be set to display different
information for the ports, including Link up or Link down. Clicking on the image of a port opens the Port Statistics page.
The port states are illustrated as follows:
State
Disabled
Down
Link
RJ45 Ports
SFP Ports
Panel Display
Main Menu
Logout
Main page
Sub Menu
