User’s Manual of IGS-5225 series
57
Per 10/100/1000BASE-T Port with PoE (Port-1~Port-8)
LED
Color
Function
10/100/1000
LNK/ACT
Green
Lights
To indicate the link through that port is successfully established.
Blinks
To indicate that the switch is actively sending or receiving data
over that port.
PoE In-Use
Amber
Lights
To indicate the port is providing 48V~56V DC in-line power.
Off
To indicate the connected device is not a PoE Powered Device
(PD)
Per 10/100/1000BASE-T Port (Port-9~Port-10)
LED
Color
Function
1000
LNK/ACT
Green
Lights
To indicate the port is successfully established at 1000Mbps.
Blinks
To indicate that the Switch is actively sending or receiving data over that port.
10/100
LNK/ACT
Amber
Lights
To indicate the port is successfully established at 100Mbps or 10Mbps.
Blinks
To indicate that the Switch is actively sending or receiving data over that port.
Per 1G/2.5GBASE-X SFP Interface
LED
Color
Function
1G/2.5G
LNK/ACT
Green
Lights
To indicate the port is successfully established at 1000Mbps or 2500Mbps.
Blinks
To indicate that the Switch is actively sending or receiving data over that port.
100
LNK/ACT
Amber
Lights
To indicate the port is successfully established at 100Mbps.
Blinks
To indicate that the Switch is actively sending or receiving data over that port.
■ PoE Power Usage (Unit: Watt)
LED
Color
Function
60
Amber
Lights:
To indicate the system consumes over 60-watt PoE power budget
120
Amber
Lights:
To indicate the system consumes over 120-watt PoE power budget
180
Amber
Lights:
To indicate the system consumes over 180-watt PoE power budget
240
Amber
Lights:
To indicate the system consumes over 240-watt PoE power budget
