User’s Manual of IGS-5225 series
36
IGMP Snooping
Ipv4 IGMP (v1/v2 /v3) Snooping
Ipv4 IGMP Querier mode support
Up to 255 multicast Groups
MLD Snooping
Ipv6 MLD (v1/v2) Snooping
Ipv6 MLD Querier mode support
Up to 255 multicast Groups
RING
Supports ERPS, and complies with ITU-T G.8032
Recovery time < 10ms @ 3 nodes
Recovery time <50ms @ 16 nodes
Supports major ring and sub-ring
Synchronization
IEEE 1588v2 PTP(Precision Time Protocol)
- Peer-to-peer transparent clock
- End-to-end transparent clock
Bandwidth Control
Per port bandwidth control
Ingress: 500Kb~1000Mbps
Egress: 500Kb~1000Mbps
QoS
Traffic classification based, strict priority and WRR
8-level priority for switching
- Port number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/TOS field in IP packet
Storm Control
Unicast/Multicast/Broadcast
Security Functions
Access Control List
IP-based ACL/MAC-based ACL
ACL based on:
- MAC Address
- IP Address
- Ethertype
- Protocol Type
- VLAN ID
- DSCP
- 802.1p Priority
Up to 512 entries
Security
Port security
IP source guard, up to 512 entries
Dynamic ARP inspection, up to 1K entries
Command line authority control based on user level
Static MAC address, up to 64 entries
AAA
RADIUS client
TACACS+ client
Network Access Control
IEEE 802.1x port-based network access control
MAC-based authentication
Local/RADIUS authentication
Management Functions
Basic Management
Interfaces
Console; Telnet; Web browser; SNMP v1, v2c
