User’s Manual of IGS-5225 series
334
4.4.1.4 Statistics
This page provides statistics for the different queues for all switch ports. The statistics screen in Figure 4-4-1-5 appears.
Figure 4-4-1-5: QoS Statistics Page Screenshot
The page includes the following fields:
Object
Description
Port
The logical port for the settings contained in the same row.
Qn
There are 8 QoS queues per port. Q0 is the lowest priority queue.
Rx/Tx
The number of received and transmitted packets per queue.
Buttons
: Click to refresh the page immediately.
:Clears the counters for all ports
