User’s Manual of IGS-5225 series
332
4.4.1.2 Queue Policing
This page allows you to configure the Queue Policer settings for all switch ports.. The Queue Policing screen in Figure 4-4-1-2
appears.
Figure 4-4-1-2 : QoS Ingress Port Classification Page Screenshot
The page includes the following fields:
Object
Description
Port
The port number for which the configuration below applies.
Enable (E)
Enable or disable the queue policer for this switch port.
Rate
Controls the rate for the queue policer. This value is restricted to 25-
13128147 when "Unit" is kbps, and 1-13128 when "Unit" is Mbps. The rate is
internally rounded up to the nearest value supported by the queue policer.
This field is only shown if at least one of the queue policers are enabled.
Unit
Controls the unit of measure for the queue policer rate as kbps or Mbps.
This field is only shown if at least one of the queue policers are enabled.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
