User’s Manual of IGS-5225 series
330
4.4.1.1 Port Classification
This page allows you to configure the basic QoS Classification settings for all switch ports. The Port classification screen in
Figure 4-4-1-1 appears.
Figure 4-4-1-1: QoS Ingress Port Policers Page Screenshot
The page includes the following fields:
Object
Description
Port
The port number for which the configuration below applies.
CoS
Controls the default CoS value.
All frames are classified to a CoS. There is a one to one mapping between CoS,
queue and priority. A CoS of 0 (zero) has the lowest priority.
The classified CoS can be overruled by a QCL entry.
Note: If the default CoS has been dynamically changed, then the actual default
CoS is shown in parentheses after the configured default CoS.
DPL
Controls the default DPL value.
All frames are classified to a Drop Precedence Level.
The classified DPL can be overruled by a QCL entry.
PCP
Controls the default PCP value.
All frames are classified to a PCP value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
the PCP value in the tag. Otherwise the frame is classified to the default PCP
value.
