User’s Manual of IGS-5225 series
328
4.3.20.2 PTP Status
This page allows the user to inspect the current PTP clock settings in Figure 4-3-20-2 appears.
Figure 4-3-20-2: PTP Clock Monitor Page
Object
Description
Inst
Indicates the Instance of a particular Clock Instance [0..3].
Click on the Clock Instance number to monitor the Clock details.
ClkDom
Indicates the Clock domain used by the Instance of a particular Clock Instance
[0..3]
Device Type
Indicates the Type of the Clock Instance. There are five Device Types
1. P2p Transp - Clock's Device Type is Peer to Peer Transparent Clock.
2. E2e Transp - Clock's Device Type is End to End Transparent Clock.
Port List
Shows the ports configured for that Clock Instance.
Buttons
Auto-refresh :: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
