User’s Manual of IGS-5225 series
324
Object
Description
Enable
Disabled or Enabled.
I/O Pin
Virtual Port I/O Pin. The valid range is 0 to 3.
Class
Clock class value for clock as defined in IEEE Std 1588. The valid range is from
0 to 255.
Accuracy
Clock accuracy value as defined in IEEE Std 1588. The valid range is 0 to 255.
Variance
offsetScaledLogVariance for clock as defined in IEEE Std 1588. The valid range
is 0 to 65535.
Pri1
Clock priority 1 [0..255] used by the BMC master select algorithm.
Pri2
Clock priority 2 [0..255] used by the BMC master select algorithm.
Local Prio
Priority [1..255]used in the 8275.1 BMCA.
Local Clock Current Time
Object
Description
PTP Time
Shows the actual PTP time with nanosecond resolution.
Clock Adjustment
Method
Shows the actual clock adjustment method. The method depends on the
available hardware.
Synchronize to
System Clock
Activate this button to synchronize the System Clock to PTP Time.
Clock current Data Set
Object
Description
stpRm
Steps Removed : It is the number of PTP clocks traversed from the grandmaster
to the local slave clock.
Offset from master
Time difference between the master clock and the local slave clock,
measured in ns.
Mean Path Delay
The mean propagation time for the link between the master and the local slave
