User’s Manual of IGS-5225 series
320
4.3.20.1 PTP Configuration
This page allows the user to configure and inspect the current PTP clock settings as screen in Figure 4-3-20-1 appears.
Figure 4-3-20-1: PTP Configuration Page Screenshot
Object
Description
Delete
Check this box and click on 'Save' to delete the clock instance.
Clock Instance
Indicates the Instance of a particular Clock Instance [0..3].
Click on the Clock Instance number to edit the Clock details
HW Domain
Indicates the HW clock domain used by the clock.
Device Type
Indicates the Type of the Clock Instance. There are five Device Types.
P2p Transp - clock's Device Type is Peer to Peer Transparent Clock.
E2e Transp - clock's Device Type is End to End Transparent Clock.
Profile
Indicates the profile used by the clock.
Click “Add New PTP Clock” to create a new clock instance
Click on the Clock Instance number to edit the Clock details
