User’s Manual of IGS-5225 series
316
Receiver Configuration
Object
Description
Onwer
Basically, sFlow can be configured in two ways: Through local management
using the Web or CLI interface or through SNMP. This read-only field shows the
owner of the current sFlow configuration and assumes values as follows:
• If sFlow is currently unconfigured/unclaimed, Owner contains <none>.
• If sFlow is currently configured through Web or CLI, Owner
contains <Configured through local management>.
• If sFlow is currently configured through SNMP, Owner contains a string
identifying the sFlow receiver.
If sFlow is configured through SNMP, all controls - except for the Release-button
- are disabled to avoid inadvertent reconfiguration.
The button allows for releasing the current owner and disable sFlow sampling.
The button is disabled if sFlow is currently unclaimed. If configured through
SNMP, the release must be confirmed (a confirmation request will appear).
IP Address/Hostname
The IP address or hostname of the sFlow receiver. Both IPv4 and IPv6
addresses are supported.
UDP Port
The UDP port on which the sFlow receiver listens to sFlow datagrams. If set to 0
(zero), the default port (6343) is used.
Timeout
The number of seconds remaining before sampling stops and the current sFlow
owner is released. While active, the current time left can be updated with a click
on the Refresh-button. If locally managed, the timeout can be changed on the fly
without affecting any other settings. Valid range is 0 to 2147483647 seconds.
Max. Datagram Size
The maximum number of data bytes that can be sent in a single sample
datagram. This should be set to a value that avoids fragmentation of the sFlow
datagrams. Valid range is 200 to 1468 bytes with default being 1400 bytes.
Port Configuration
Object
Description
Port
The port number for which the configuration below applies.
Flow Sampler Enabled
Enables/disables flow sampling on this port.
Flow Sampler
Sampling Rate
The statistical sampling rate for packet sampling. Set to N to sample on average
1/Nth of the packets transmitted/received on the port.
Not all sampling rates are achievable. If an unsupported sampling rate is
requested, the switch will automatically adjust it to the closest achievable. This
will be reported back in this field. Valid range is 1 to 32767.
Flow Sampler Max.
Header
The maximum number of bytes that should be copied from a sampled packet to
the sFlow datagram. Valid range is 14 to 200 bytes with default being 128 bytes.
To have room for any frame, the maximum datagram size should be roughly 100
