User’s Manual of IGS-5225 series
312
The following explains the settings when configuring the MEP.
Object
Description
Delete
Check to delete the entry. It will be deleted during the next save.
Domain
Name of Domain under which this Service resides.
Name
Name of Service under which this MEP resides.
MEPID
The identification of this MEP. Must be an integer [1..8091]
Direction
Set whether this MEP is an Up- or a Down-MEP.
Port
Port on which this MEP resides.
VLAN
VLAN ID. Use the value 0 to indicate untagged traffic (implies a port MEP)..
PCP
Choose PCP value in PDUs' VLAN tag. Not used if untagged.
SMAC
Set a Source MAC address to be used in CCM PDUs originating at this MEP.
Must be a unicast address. Format is XX:XX:XX:XX:XX:XX. If all-zeros, the
switch port's MAC address will be used instead.
Alarm Control
Level: If a defect is detected with a priority higher than this level, a fault alarm
notification will be generated.
Valid range is [1; 6] with 1 indicating that any defect will cause a fault alarm and
6 indicating that no defect can cause a fault alarm. See 802.1Q-2018, clause
20.9.5, LowestAlarmPri
The possible defects and their priorities are:
Short name
Description
Priority
DefRDICCM
Remote Defect Indication
1
DefMACstatus
MAC Status
2
DefRemoteCCM
Remote CCM
3
DefErrorCCM
Error CCM Received
4
DefXconCCM
Cross Connect CCM Received
5
Present: The time in milliseconds that defects must be present before a fault
alarm notification is issued. Default is 2500 ms.
Absent: The time in milliseconds that defects must be absent before a fault
alarm notification is reset. Default is 10000 ms.
State Control
CCM: Enable or disable generation of continuity-check messages (CCMs)
Admin: Enable or disable this MEP. When this MEP is enabled, it will check
received/missing CCMs and can raise defects.
Remote MEPID
Specify the Remote MEP that this MEP is expected to receive CCM PDUs from.
Must be an integer [0..8091] where 0 means undefined. The value of Remote
MEPID must be different from the value of MEPID.
