User’s Manual of IGS-5225 series
292
4.3.16.2 UDLD Status
This page displays the UDLD status of the ports as well. as screen in Figure 4-3-16-2 appears.
Figure 4-3-16-2: UDLD status Page Screenshot
The page includes the following fields:
UDLD port status
Object
Description
UDLD Admin State
The current port state of the logical port, Enabled if any of
state(Normal,Aggressive) is Enabled.
Device ID(local)
The ID of Device
Device Name(local)
Name of the Device.
Bidirectional State
The current state of the port.
Neighbour Status
Object
Description
Port
The current port of neighbour device
Device ID
The current ID of neighbour device.
Link Status
The current link status of neighbour port.
Device Name
Name of the Neighbour Device.
Buttons
: Click to refresh the page immediately.
