User’s Manual of IGS-5225 series
290
4.3.15.2 Loop Protection Status
This page displays the loop protection port status of the switch; screen in Figure 4-3-15-2 appears.
Figure 4-3-15-2: Loop Protection Status Screenshot
The page includes the following fields:
Object
Description
Port
The Industrial Managed Switch port number of the logical port.
Action
The currently configured port action.
Transmit
The currently configured port transmit mode.
Loops
The number of loops detected on this port.
Status
The current loop protection status of the port.
Loop
Whether a loop is currently detected on the port.
Time of Last Loop
The time of the last loop event detected.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
