User’s Manual of IGS-5225 series
273
Device is detected, will an LLDP-MED capable Network Connectivity Device
start to advertise LLDP-MED TLVs in outgoing LLDPDUs on the associated port.
The LLDP-MED application will temporarily speed up the transmission of the
LLDPDU to start within a second, when a new LLDP-MED neighbour has been
detected in order share LLDP-MED information as fast as possible to new
neighbours.
Because there is a risk of an LLDP frame being lost during transmission
between neighbours, it is recommended to repeat the fast start transmission
multiple times to increase the possibility of the neighbours receiving the LLDP
frame. With Fast start repeat count it is possible to specify the number of times
the fast start transmission would be repeated. The recommended value is 4
times, given that 4 LLDP frames with a 1 second interval will be transmitted,
when an LLDP frame with new information is received.
It should be noted that LLDP-MED and the LLDP-MED Fast Start mechanism is
only intended to run on links between LLDP-MED Network Connectivity Devices
and Endpoint Devices, and as such does not apply to links between LAN
infrastructure elements, including Network Connectivity Devices, or other types
of links.
LLDP-MED Interface Configuration
Object
Description
Interface
The interface name to which the configuration applies.
Transmit TLVs -
Capabilities
When checked the switch's capabilities is included in LLDP-MED information
transmitted
Transmit TLVs -
Policies
When checked the configured policies for the interface is included in LLDP-
MED information transmitted.
Transmit TLVs -
Location
When checked the configured location information for the switch is included
in LLDP-MEDinformation transmitted.
Transmit TLVs - PoE
When checked the configured PoE (Power Over Ethernet) information for the
interface is included in LLDP-MED information transmitted
Device Type
Any LLDP-MED Device is operating as a specific type of LLDP-MED Device,
which may be either a Network Connectivity Device or a specific Class of
Endpoint Device, as defined below.
A Network Connectivity Device is a LLDP-MED Device that provides access to
the IEEE 802 based LAN infrastructure for LLDP-MED Endpoint Devices
An LLDP-MED Network Connectivity Device is a LAN access device based on
any of the following technologies :
1. LAN Switch/Router
2. IEEE 802.1 Bridge
