User’s Manual of IGS-5225 series
235
4.3.9.5 MSTI Priorities
This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them
as well. The MSTI Priority screen in Figure 4-3-9-7 appears.
Figure 4-3-9-7: MSTI Priority Page Screenshot
The page includes the following fields:
Object
Description
MSTI
The bridge instance. The CIST is the default instance, which is always active.
Priority
Controls the bridge priority. Lower numerical values have better priority. The
bridge priority plus the MSTI instance number, concatenated with the 6-byte
MAC address of the switch forms a Bridge Identifier.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
