User’s Manual of IGS-5225 series
215
b. PID: PID (Protocol ID). If OUI is hexadecimal 000000, then the protocol ID is
the Ethernet type (EtherType) field value for the protocol running on top of
SNAP; if OUI is an OUI for a particular organization, the protocol ID is a value
assigned by that organization to the protocol running on top of SNAP.
In other words, if the value of OUI field is 00-00-00 then the value of PID will be
etype (0x0600-0xffff) and if the value of OUI is other than 00-00-00 then valid
values of PID will be any value between 0x0000 and 0xffff.
Group Name
A valid Group Name is a 16-character long string, unique for every entry, which
consists of a combination of alphabets (a-z or A-Z) and integers(0-9).
Note: Special characters and underscores (_) are not allowed.
Adding New Entries
Click to add a new entry in the mapping table. An empty row
is added to the table, where Frame Type, Value and the Group Name can be
configured as needed.
The button can be used to undo the addition of new entry. The
maximum possible Protocol to Group mappings are limited to 128.
