User’s Manual of IGS-5225 series
211
The table below explains the manageable items shown on this page.
Object
Description
Delete
To delete a Group Name to VLAN map entry, check this box. The entry will be
deleted on the switch during the next Save
Private VLAN ID
Indicates the ID of this particular private VLAN.
Port Members
A row of check boxes for each port is displayed for each private VLAN ID. To
include a port in a Private VLAN, check the box. To remove or exclude the port
from the Private VLAN, make sure the box is unchecked. By default, no ports
are members, and all boxes are unchecked.
Adding a New Private
VLAN
Click to add a new private VLAN ID. An empty row
is added to the table, and the private VLAN can be configured as needed. The
allowed range for a private VLAN ID is the same as the switch port number
range. Any values outside this range are not accepted, and a warning message
appears. Click "OK" to discard the incorrect entry, or click "Cancel" to return to
the editing and make a correction.
The Private VLAN is enabled when you click "Save".
4.3.5.2 Port Isolation
This page is used to enable or disable port isolation on ports in a Private VLAN.
A port that is a member of a VLAN can be isolated from other ports on the same VLAN and Private VLAN.
Figure 4-3-5-2: Port Isolation Configuration
Configuration:
Object
Description
Port Members
A checkbox is provided for each port of a private VLAN. When checked, port
isolation is enabled on that port. When unchecked, port isolation is disabled on
that port. By default, port isolation is disabled on all ports.
