User’s Manual of IGS-5225 series
187
4.3.2.9 LACP Port Statistics
This page provides an overview for LACP statistics for all ports. The LACP Port Status screen in Figure 4-3-2-8 appears.
Figure 4-3-2-8: LACP Port Statistics Page Screenshot
The page includes the following fields:
Object
Description
Port
The switch port number.
LACP Received
Shows how many LACP frames have been received at each port.
LACP Transmitted
Shows how many LACP frames have been sent from each port.
Discarded
Shows how many unknown or illegal LACP frames have been discarded at each
port.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Clears the counters for all ports.
