User’s Manual of IGS-5225 series
183
4.3.2.5 LACP System Status
This page provides a status overview of all LACP instances. The LACP Status Page display the current LACP aggregation
Groups and LACP Port status. The LACP System Status screen in Figure 4-3-2-6 appears.
Figure 4-3-2-6: LACP System Status Page Screenshot
The page includes the following fields:
Object
Description
Aggr ID
The Aggregation ID associated with this aggregation instance.
For LLAG the id is shown as 'isid:aggr-id' and for GLAGs as 'aggr-id'
Partner System ID
The system ID (MAC address) of the aggregation partner.
Partner Key
The Key that the partner has assigned to this aggregation ID.
Partner Priority
The priority of the aggregation partner.
Last Changed
The time since this aggregation changed.
Local Ports
Shows which ports are a part of this aggregation for this switch.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Automatic refresh occurs every 3 seconds.
