User’s Manual of IGS-5225 series
181
4.3.2.3 Aggregation Status
This page is used to see the staus of ports in Aggregation group. The Static Aggregation Status screen in Figure 4-3-2-4
appears.
Figure 4-3-2-4 : LACP Port Configuration Page Screenshot
The page includes the following fields:
Object
Description
Aggr ID
Display the Aggregation ID associated with this aggregation instance.
Name
Display the Name of the Aggregation group ID.
Type
Display the type of the Aggregation group(Static or LACP).
Speed
Display the Speed of the Aggregation group.
Configured Ports
Display the Configured member ports of the Aggregation group.
Aggregated Ports
Display the Aggregated member ports of the Aggregation group.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Automatic refresh occurs every 3 seconds.
