User’s Manual of IGS-5225 series
179
4.3.2.1 Common
This page is used to configure the Aggregation hash mode and the aggregation group. The aggregation hash mode settings
are global.
Hash Code Contributors
The Static Aggregation screen in Figure 4-3-2-2 appears.
Figure 4-3-2-2 : Aggregation Mode Configuration Page Screenshot
The page includes the following fields:
Object
Description
Source MAC Address
The Source MAC address can be used to calculate the destination port for the
frame. Check to enable the use of the Source MAC address, or uncheck to
disable. By default, Source MAC Address is enabled.
Destination MAC
Address
The Destination MAC Address can be used to calculate the destination port for
the frame. Check to enable the use of the Destination MAC Address, or uncheck
to disable. By default, Destination MAC Address is disabled.
IP Address
The IP address can be used to calculate the destination port for the frame.
Check to enable the use of the IP Address, or uncheck to disable. By default, IP
Address is enabled.
TCP/UDP Port Number
The TCP/UDP port number can be used to calculate the destination port for the
frame. Check to enable the use of the TCP/UDP Port Number, or uncheck to
disable. By default, TCP/UDP Port Number is enabled.
