User’s Manual of IGS-5225 series
176
4.3.1.9 DDMI Detailed
Display DDMI detailed information on this page.
The displayed settings are:
Object
Description
Vendor
Indicates SFP vendor name.
Part Number
Indicates part number provided by SFP vendor.
Serial Number
Indicates part number provided by SFP vendor.
Revision
Indicates revision level for part number provided by SFP vendor.
Data Code
Indicates vendor's manufacturing date code.
Transceiver
Indicates SFP transceiver compatibility.
DDMI Information
Display DDMI information on this page.
Current
The current value of temperature, voltage, Tx bias, Tx power, and Rx power.
Alarm/Warning
Indicates whether there is an alarm or warning.
Low Warning
Threshold
The low warning threshold value of temperature, voltage, Tx bias, Tx power, and
Rx power.
High Warning
Threshold
The high warning threshold value of temperature, voltage, Tx bias, Tx power,
and Rx power.
Low Alarm Threshold
The low alarm threshold value of temperature, voltage, Tx bias, Tx power, and
Rx power.
High Alarm Threshold
The high alarm threshold value of temperature, voltage, Tx bias, Tx power, and
Rx power.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
