User’s Manual of IGS-5225 series
170
The page includes the following fields:
Object
Description
Type
Display the type of current SFP module; the possible types are:
10GBASE-SR
10GBASE-LR
1000BASE-SX
1000BASE-LX
100BASE-FX
Speed
Display the speed of current SFP module; the speed value or description is got
from the SFP module. Different vendors SFP modules might show different
speed information.
Wave Length (nm)
Display the wavelength of current SFP module; the wavelength value is got from
the SFP module. Use this column to check if the wavelength values of two
nodes are matched while the fiber connection failed.
Distance (m)
Display the support distance of current SFP module; the distance value is got
from the SFP module.
Temperature (C)
– SFP DDM Module Only
Display the temperature of current SFP DDM module; the temperature value is
got from the SFP DDM module.
Voltage(V)
– SFP DDM Module Only
Display the voltage of current SFP DDM module; the voltage value is got from
the SFP DDM module.
Current(mA)
– SFP DDM Module Only
Display the Ampere of current SFP DDM module; the Ampere value is got from
the SFP DDM module.
TX power (dBm)
– SFP DDM Module Only
Display the TX power of current SFP DDM module; the TX power value is got
from the SFP DDM module.
RX power (dBm)
– SFP DDM Module Only
Display the RX power of current SFP DDM module; the RX power value is got
from the SFP DDM module.
Buttons
SFP Monitor Event Alert: send trap
Warning Temperature: degrees C
Check SFP Monitor Event Alert box; it will be in accordance with your warning temperature setting and allows users to
record message out via SNMP Trap.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to refresh the page immediately.
