User’s Manual of IGS-5225 series
161
4.2.6 Industrial Protocol
With the supported Modbus TCP/IP protocol, the IGS-5225 series can easily integrate with SCADA systems, HMI systems and
other data acquisition systems in factory floors. It enable administrators to remotely monitor the industrial Ethernet
switch’s operating information, port information and communication status, thus easily achieving enhanced monitoring
and maintenance of the entire factory.
4.2.6.1 Protocol Configuration
The Industrial Protocol Configuration are configured here.; screen in Figure 4-2-5-1 appears.
Figure 4-2-5-1: Protocol Configuration Page Screenshot
The page includes the following fields:
Object
Description
Modbus TCP Mode
Indicates the modbus TCP mode operation. Possible modes are:
Enabled: Enable modbus TCP mode operation.
Disabled: Disable modbus TCP mode operation.
Buttons
: Click to apply changes
