User’s Manual of IGS-5225 series
154
Mode
Indicate the operation mode per VLAN. Possible modes are:
Enabled: Enable DHCP server per VLAN.
Disabled: Disable DHCP server pre VLAN.
Buttons
: Click to add a new VLAN range.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.2.5.2 Excluded IP
Configure excluded IP addresses. DHCP server will not allocate these excluded IP addresses to DHCP client.; screen in Figure
4-2-4-2 appears.
Figure 4-2-4-2: DHCP server excluded Page Screenshot
The page includes the following fields:
Object
Description
IP range
Define the IP range to be excluded IP addresses. The first excluded IP must be
smaller than or equal to the second excluded IP. BUT, if the IP range contains
only 1 excluded IP, then you can just input it to either one of the first and second
excluded IP or both.
Buttons
: Click to add a new excluded IP range.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
