User’s Manual of IGS-5225 series
148
4.2.4 DHCP Relay
(Only applies to switches installed with firmware after vx.2103bxxxxxx )
4.2.4.1 DHCPv4 Relay
A DHCP relay agent is used to forward and to transfer DHCP messages between the clients and the server when
they are not in the same subnet domain. It stores the incoming interface IP address in the GIADDR field of the
DHCP packet. The DHCP server can use the value of GIADDR field to determine the assigned subnet. For such
condition, please make sure the switch configuration of VLAN interface IP address and PVID(Port VLAN ID)
correctly.
Figure 4-2-4-1: DHCPv4 Relay Configuration
The page includes the following fields:
DHCPv4 Relay
Configure operation mode to enable/disable DHCP server per system.
Object
Description
Relay Mode
Indicates the DHCP relay mode operation.
Possible modes are:
Enabled: Enable DHCP relay mode operation. When DHCP relay mode
operation is enabled, the agent forwards and transfers DHCP messages
between the clients and the server when they are not in the same subnet
domain. And the DHCP broadcast message won't be flooded for security
considerations.
Disabled: Disable DHCP relay mode operation.
