User’s Manual of IGS-5225 series
144
4.2.3.6 RMON History Status
This page provides an detail of RMON history entries; screen in Figure 4-2-3-6 appears.
Figure 4-2-3-6: RMON History Overview Page Screenshot
The page includes the following fields:
Object
Description
History Index
Indicates the index of History control entry.
Sample Index
Indicates the index of the data entry associated with the control entry.
Sample Start
The value of sysUpTime at the start of the interval over which this sample was measured.
Drop
The total number of events in which packets were dropped by the probe due to lack of
resources.
Octets
The total number of octets of data (including those in bad packets) received on the network.
Pkts
The total number of packets (including bad packets, broadcast packets, and multicast packets)
received.
Broadcast
The total number of good packets received that were directed to the broadcast address.
Multicast
The total number of good packets received that were directed to a multicast address.
CRC Errors
The total number of packets received that had a length (excluding framing bits, but including
FCS octets) of between 64 and 1518 octets, inclusive, but had either a bad Frame Check
Sequence (FCS) with an integral number of octets (FCS Error) or a bad FCS with a non-
integral number of octets (Alignment Error).
Undersize
The total number of packets received that were less than 64 octets.
Oversize
The total number of packets received that were longer than 1518 octets.
Frag.
The number of frames whose size is less than 64 octets received with invalid CRC.
Jabb.
The number of frames whose size is larger than 64 octets received with invalid CRC.
Coll.
The best estimate of the total number of collisions in this Ethernet segment.
Utilization
The best estimate of the mean physical layer network utilization on this interface during this
sampling interval, in hundredths of a percent.
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Updates the table, starting from the first entry in the History table, i.e., the entry with the lowest History
Index and Sample Index
: Updates the table, starting with the entry after the last entry currently displayed.
