User’s Manual of IGS-4215 DIN-rail Series
82
4.2.4 Global IP Configuration
The Global IP Configuration encompasses both IP Route Configuration and DNS Configuration. This process involves setting
the IP Route Mode and DNS Server, as well as displaying the current information on the Industrial Managed Switch. The
screens in Figure 4-2-4-1 and Figure 4-2-4-2 appear.
Figure 4-2-4-1: Global IP Configuration Screenshot
The IP Route Configuration and DNS Configuration Settings include the following fields:
Object
Description
Router Mode
Configure the IP stack to function as a router. When Route Mode is enabled, IP
traffic is routed between all interfaces. Conversely, when Route Mode is disabled,
IP traffic between interfaces will not be routed.
DNS Server From
DHCP
Configure whether the DNS server information is provided by the DHCP server.
DNS Server 1/2
Provide the IP address of the DNS server in dotted decimal notation.
Figure 4-2-4-2: IP Information Screenshot
The IP Information includes the following fields:
Object
Description
Router Mode
Displays whether the IP stack should function as a router. When Route Mode is
enabled, IP traffic is routed between all interfaces. Conversely, when Route
Mode is disabled, IP traffic between interfaces will not be routed.
Current DNS Server 1/2
Displays the IP address of the DNS Server in dotted decimal notation.
Buttons
: Click to apply changes.
