User’s Manual of IGS-4215 DIN-rail Series
80
4.2.3 IPv6 Configuration
The IPv6 Configuration includes the IPv6 Interface Setting and Vlan interface status. Fill out the Auto Configuration and IPv6
Address for the VLAN interface. The maximum number of interfaces supported is 64.The screens in Figure 4-2-3-1 to Figure 4-
2-3-3 appear.
The configured column is used to specify the VLAN ID to which you would like to assign the IPv6 interface.
Figure 4-2-3-1: IPv6 Interface Setting Screenshot
The IPv6 Interface Settings include the following fields:
Object
Description
VLAN Interface
Choose the VLAN ID to which you would like to add the IPv6 interface.
Auto Configuration
Enable IPv6 auto-configuration by checking this box.
If it fails, the configured IPv6 address is zero. The router may delay responding to
a router solicitation for a few seconds; the total time needed to complete auto-
configuration can be significantly longer.
IPv6 Address
Provide the IPv6 address for the VLAN interface.
IPv6 address is in 128-bit records represented as eight fields of up to four
hexadecimal digits with a colon separating each field (:). For example,
'fe80::215:c5ff:fe03:4dc7'.
The symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can only appear
once. It also uses the following legally IPv4 address.
For example, ':192.1.2.34'.
Provide the IPv6 Prefix of this switch.
The allowed range is 1 through 128.
DHCPv6 Client
To enable this Industrial Managed Switch to accept a configuration from a
Dynamic Host Configuration Protocol version 6 (DHCPv6) server.
By default, the Industrial Managed Switch does not perform DHCPv6 client
actions. DHCPv6 clients request the delegation of long-lived prefixes that they
can push to individual local hosts.
