User’s Manual of IGS-4215 DIN-rail Series
79
Figure 4-2-2-2: VLAN IPv4 Interface Status Screenshot
The VLAN Interface Status includes the following fields:
Object
Description
VLAN Interface
Displays all current VLAN interfaces.
IP Mode
Displays the IP address mode of operation for all current VLAN interfaces.
IP Address
Displays the IP address of all current VLAN interfaces.
Netmask
Displays the Netmask of all current VLAN interfaces.
Modify
Click the button to modify the IP interface configuration.
Buttons
: Click to add a new IP interface. A maximum of 64 interfaces are supported.
: Click to delete the selected IP interface.
: Click to edit the IP interface configuration.
Figure 4-2-2-3: Screenshot of the IPv4 Interface Settings Edit Page
