User’s Manual of IGS-4215 DIN-rail Series
61
MTB-LR60
10G
LC
Single Mode
60km
1310nm
-
0 ~ 60°C
MTB-LR80
10G
LC
Single Mode
80km
1310nm
-
0 ~ 60°C
MTB-TSR2
10G
LC
Single Mode
2km
1310nm
-
-40 ~ 85°C
MTB-TLR20
10G
LC
Single Mode
20km
1310nm
-
-40 ~ 85°C
MTB-TLR60
10G
LC
Single Mode
60km
1310nm
-
-40 ~ 85°C
MTB-TLA20
10G
LC
Single Mode
20km
1270nm
1330nm
-40 ~ 85°C
MTB-TLB20
10G
LC
Single Mode
20km
1330nm
1270nm
-40~85°C
MTB-LA10
10G
LC
Single Mode
10km
1270nm
1330nm
0 ~ 60°C
MTB-LB10
10G
LC
Single Mode
10km
1330nm
1270nm
0 ~ 60°C
MTB-TLB40
10G
LC
Single Mode
40km
1330nm
1270nm
-40 ~ 85°C
MTB-TLA40
10G
LC
Single Mode
40km
1270nm
1330nm
-40 ~ 85°C
MTB-TLA60
10G
LC
Single Mode
60km
1270nm
1330nm
-40 ~ 85°C
MTB-TLB60
10G
LC
Single Mode
60km
1330nm
1270nm
-40 ~ 85°C
It is recommended to use PLANET SFPs on the Industrial Managed Switch. If you insert an
SFP transceiver that is not supported, the Industrial Managed Switch might not recognize it.
Please choose the SFP transceiver which can be operated in the temperature range of -40~75
degrees C.
1. Before we connect the Industrial 10G Managed Media Converter to the other network device, we have to make sure both
sides of the SFP transceivers are with the same media type, for example: 10GBASE-SX to 10GBASE-SX, 1000BASE-
LX to 1000BASE-LX.
2. Check whether the fiber-optic cable type matches with the SFP transceiver requirement.
To connect to 1000BASE-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male
duplex LC connector type.
To connect to 1000BASE-LX SFP transceiver, please use the single-mode fiber cable with one side being the male
duplex LC connector type.
Connect the fiber cable
1. Insert the duplex LC connector into the SFP/SFP+ transceiver.
2. Connect the other end of the cable to a device with SFP/SFP+ transceiver installed.
3. Check the LNK/ACT LED of the SFP/SFP+ slot on the front of the Industrial 10G Managed Media Converter. Ensure that
the SFP/SFP+ transceiver is operating correctly.
4. Check the Link mode of the SFP/SFP+ port if the link fails. To function with some fiber-NICs or Media Converters, user
has to set the port Link mode to “10G FDX”, “2.5G FDX”, “1000M FDX” or “100M FDX”.
