User’s Manual of IGS-4215 DIN-rail Series
46
IGS-4215-16P4X
System
LED
Color
Function
PWR 1
Green
Lights to indicate DC power input 1 has power.
PWR 2
Green
Lights to indicate DC power input 2 has power.
Alarm
Red
Lights to indicate that Switch power input or port has failed.
Ring
Green
Lights to indicate that the ERPS Ring has been created successfully.
R.O.
Green
Lights to indicate that Ring state is in idle mode.
Blinks to indicate that the Ring state is in protected mode.
I/O
Red
Blinks to indicate that Switch input power or port has failed or DI has event.
10/100/1000BASE-T, 802.3at RJ45 Ports (Ports 1 to 16)
LED
Direction
LED
Color
Function
Up
1000 LNK/ACT
Green
Lights
To indicate the port is running at 1000Mbps and is successfully
established.
10/100 LNK/ACT
Amber
Blinks
To indicate the port is running at 10Mbps and 100Mbps, and is
successfully established.
Down
PoE-in-Use
Amber
Lights
Lights to indicate the PoE port is working in 802.3at PoE+ and
offers up to 36 watts of power.
100/1G/2.5G/10GBASE-X SFP Interfaces (Ports XG1 to XG4)
LED
Color
Function
1G/2.5G
LNK/ACT
Green
Lights
To indicate the port is successfully established at 1Gbps/2.5Gbps.
Blinks
To indicate that the switch is actively sending or receiving data over that port.
100/10G
LNK/ACT
Amber
Lights
To indicate the port is successfully established at 100Mbps/10Gbps.
Blinks
To indicate that the switch is actively sending or receiving data over that port.
