User’s Manual of IGS-4215 DIN-rail Series
30
802.3at PoE: End-span: 1/2(-), 3/6(+)
802.3at PoE: End-span: 1/2(-), 3/6(+)
802.3at PoE: Mid-span: 4/5(+), 7/8(-)
-
PoE Power Output
Per port 48V ~ 54VDC
IEEE 802.3af Standard
802.3bt Type-4 mode: maximum 95 watts
Per port 48V~51V DC, max. 15.4 watts
802.3bt Type-3 mode: maximum 60 watts
IEEE 802.3at Standard
End-span mode: maximum 36 watts
Per port 51V~54V DC, max. 36 watts
Mid-span mode: maximum 36 watts
-
Force mode: maximum 95 watts
-
PoE Power Budget
Single power input: 240W maximum (depending on power input)
Dual power input: 360W maximum (depending on power input)
※Dual power input must be the same as DC voltage, like dual 54V.
Max. Number of 90W 802.3bt
Type 4 PDs
4
-
Max. Number of 60W 802.3bt
Type 3 PDs
6
-
Max. Number of 30W 802.3at
Type 2 PDs
8
12
PoE Management Functions
PoE Management
PD Alive Check
Scheduled Power Recycling
PoE Schedule
PoE Usage Monitoring
PoE Extension
Enhanced PoE Mode
Standard/Legacy/Force
Active PoE Device Live
Detection
Yes
PoE Power Recycling
Yes, daily or predefined schedule
PoE Schedule
4 schedule profiles
PoE Extend Mode
Yes, max. up to 250 meters
Layer 2 Functions
Port Mirroring
TX/RX/Both
Many-to-1 monitor
Up to 4 sessions
VLAN
802.1Q tagged VLAN
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
