User’s Manual of IGS-4215 DIN-rail Series
21
1.4 Product Features
Physical Port
■ 8/16/24 10/100/1000BASE-T Gigabit Ethernet RJ45 ports
■ PoE Functionality:
16 ports with IEEE 802.3at PoE+ injector function (IGS-4215-16P4X)
8 ports with IEEE 802.3bt PoE++ injector function (IGS-4215-8UP4X)
■ 4 10GBASE-SR/LR SFP+ slots, backward compatible with 1G/2.5GBASE-X SFP
■ One USB Type C console interface for basic management and setup
Power over Ethernet (PoE functionality is exclusive for the IGS-4215-8UP4X & IGS-4215-16P4X.)
■ Compliance with IEEE 802.3bt Type-4 PoE++ standard and backward compatible with IEEE 802.3af/at Power over
Ethernet (exclusive to IGS-4215-8UP4X)
■ Powers up to 8 ports of IEEE 802.3bt PoE++ devices (exclusive to IGS-4215-8UP4X)
■ Powers up to 16 ports of IEEE 802.3at PoE+ devices (exclusive to IGS-4215-16P4X)
■ PoE budget (Both IGS-4215-8UP4X & IGS-4215-16P4X)
Dual power input: 360W
Single power input: 240W
■ Supports PoE power up to 95 watts for each PoE port (IGS-4215-8UP4X)
■ Supports PoE power up to 36 watts for each PoE+ port (IGS-4215-16P4X)
■ Auto detects powered devices (PDs)
■ Circuit protection prevents power interference between ports
■ Remote power feeding up to 100 meters in standard mode and 250m in extended mode
IGS-4215-8UP4X: 40W
IGS-4215-16P4X: 15W
■ PoE management
Total PoE power budget control
Per port PoE function enable/disable
PoE port power feeding priority
Per PoE port power limitation
PD classification detection
■ Intelligent PoE features
Temperature threshold control
PoE extension
PD alive check
PoE schedule
Industrial Case and Installation
■ IP30 aluminum case
■ DIN-rail and wall-mount designs
■ IGS-4215-8UP4X/IGS-4215-16P4X: 48~54V DC (redundant power with reverse polarity protection)
■ IGS-4215-8T4X/IGS-4215-16T4X/IGS-4215-24T4X: 9~48V DC (redundant power with reverse polarity protection) or
24V AC input
■ Supports 6KVDC Ethernet ESD protection
■ -40 to 75 °C operating temperature
Digital Input and Digital Output
■ 2 digital input (DI)
■ 2 digital output (DO)
■ Integrate sensors into auto alarm system
■ Transfer alarm to IP network via SNMP trap
